ssh整合redis存储验证码
- SSM整合redis存储验证码
- 思路
- **获取验证码部分：**
- **登录部分**
- 细节
- 详细代码
- 前端
- 后端
- SSH
- 思路：
- 测试redis是否连接成功
- 详细代码
- 后端
- 前台
SSM整合redis存储验证码
思路
登录界面向后台请求验证码，后台就先调用随机函数生成验证码，并且根据验证码生成一张图片，以 base64 字符串的形式传到前台，这时我们还要生成verificationJwt令牌做为请求验证码客户端的区分。我们先将验证码信息存入redis。key是 verificationJwt令牌的值，value就是验证码了。并且将令牌放入到响应头。传给客户端。当客户端提交的时候将保持的verificationJwt令牌放入请求头带过来。后端根据前端传过来的 jwt令牌去redis中获取数据，将验证码拿到后和现有的验证码进行比较。看看是否相等
思路图解
获取验证码部分：
图解1.这里全文都使用着两个令牌**，一张是jwt令牌（用于判断是否登录后所看到的资源），一张是verificationJwt(验证码)**
图解2.登录界面向后台请求验证码，后台就先调用随机函数生成验证码，并且根据验证码生成一张图片，以 base64 字符串的形式传到前台，这时我们还要生成verificationJwt令牌做为请求验证码客户端的区分。我们先将验证码信息存入redis。key是 verificationJwt令牌的值，value就是验证码了。
并将令牌放入到响应头。传给客户端
（Debug调试）
redis存储成功
得到后台相应返回的头verificationjwt
保存verificationJwt到vuex
登录部分
当客户端提交的时候将保持的verificationJwt令牌放入请求头带过来。后端根据前端传过来的 jwt令牌去redis中获取数据，将验证码拿到后和现有的验证码进行比较。看看是否相等
细节
注意：
这里请求头同时发送了两个jwt,还有验证码的jwt,访问报404forbidden，
原因：
jwt是用来登录
verificationJwt
详细代码
前端
State.js（定义vuex变量）
export default {resturantName: '飞歌餐馆',jwt:'',options: [],//存放tab页的容器activeIndex: '',//激活的tab页路由路径showName:'show',//tab页的标题role:"",//用来区分是否是因为左侧菜单被点击造成的路由路径发生改变，是：pass；不是：nopassverificationJwt:null, //这是用来保存用户等登录验证码jwt身份识别的
}
Mutations.js（set方法）
setVerificationJwt: (state, payload) => {state.verificationJwt = payload.verificationJwt;}
Getters.js（get方法）
getVerificationJwt:(state) =>{return state.verificationJwt;}
action.js
/*** 对后台请求的地址的封装，URL格式如下：* 模块名_实体名_操作*/
export default {//ssh
// 'SERVER': 'http://localhost:8080/T216_SSH', //服务器
// 'SYSTEM_USER_DOLOGIN': '/vue/userAction_login.action', //用户登陆
// 'VERIFICATION': '/vue/userAction_userCode.action', //验证码验证// ssm'SERVER': 'http://localhost:8080/ssm', //服务器'SYSTEM_USER_DOLOGIN': '/vue/user/login', //用户登陆'VERIFICATION': '/vue/user/verificationCode', //验证码验证'SYSTEM_USER_DOREG': '/vue/userAction_reg.action', //用户注册'SYSTEM_MENU_TREE': '/vue/treeNodeAction.action', //左侧树形菜单加载'SYSTEM_ARTICLE_LIST': '/vue/articleAction_list.action', //文章列表'SYSTEM_ARTICLE_ADD': '/vue/articleAction_add.action', //文章新增'SYSTEM_ARTICLE_EDIT': '/vue/articleAction_edit.action', //文章修改'SYSTEM_ARTICLE_DEL': '/vue/articleAction_del.action', //文章删除'SYSTEM_USER_GETASYNCDATA': '/vue/userAction_getAsyncData.action', //vuex中的异步加载数据'getFullPath': k => { //获得请求的完整地址，用于mockjs测试时使用return this.SERVER + this[k];}
}http.js
/*** vue项目对axios的全局配置*/
import axios from 'axios'
import qs from 'qs'//引入action模块，并添加至axios的类属性urls上
import action from '@/api/action'
axios.urls = action// axios默认配置
axios.defaults.timeout = 10000; // 超时时间
// axios.defaults.baseURL = 'http://localhost:8080/j2ee15'; // 默认地址
axios.defaults.baseURL = action.SERVER;//整理数据
// 只适用于 POST,PUT,PATCH，transformRequest` 允许在向服务器发送前，修改请求数据
axios.defaults.transformRequest = function(data) {data = qs.stringify(data);return data;
};// 请求拦截器
axios.interceptors.request.use(function(config) {//设置验证码jwt令牌let verificationJwt = window.vm.$store.getters.getVerificationJwt;if (verificationJwt) {config.headers['verificationJwt'] = verificationJwt;}var jwt = window.vm.$store.getters.getJwt;config.headers['jwt'] = jwt;return config;
}, function(error) {return Promise.reject(error);
});// 响应拦截器axios.interceptors.response.use(function(response) {// debugger;//保存验证码jwt令牌let verificationjwt = response.headers['verificationjwt'];if (verificationjwt) {window.vm.$store.commit('setVerificationJwt', {verificationJwt: verificationjwt});}var jwt = response.headers['jwt'];if (jwt) {window.vm.$store.commit('setJwt', {jwt: jwt});}return response;
}, function(error) {return Promise.reject(error);
});// // 路由请求拦截
// // http request 拦截器
// axios.interceptors.request.use(
// config => {
// //config.data = JSON.stringify(config.data);
// //config.headers['Content-Type'] = 'application/json;charset=UTF-8';
// //config.headers['Token'] = 'abcxyz';
// //判断是否存在ticket，如果存在的话，则每个http header都加上ticket
// // if (cookie.get("token")) {
// // //用户每次操作，都将cookie设置成2小时
// // cookie.set("token", cookie.get("token"), 1 / 12)
// // cookie.set("name", cookie.get("name"), 1 / 12)
// // config.headers.token = cookie.get("token");
// // config.headers.name = cookie.get("name");
// // }
// return config;
// },
// error => {
// return Promise.reject(error.response);
// });// // 路由响应拦截
// // http response 拦截器
// axios.interceptors.response.use(
// response => {
// if (response.data.resultCode == "404") {
// console.log("response.data.resultCode是404")
// // 返回 错误代码-1 清除ticket信息并跳转到登录页面
// // cookie.del("ticket")
// // window.location.href='http://login.com'
// return
// } else {
// return response;
// }
// },
// error => {
// return Promise.reject(error.response) // 返回接口返回的错误信息
// });export default axios;后端
redis的pom.xml
<dependency><groupId>redis.clients</groupId><artifactId>jedis</artifactId><version>${redis.version}</version></dependency><dependency><groupId>org.springframework.data</groupId><artifactId>spring-data-redis</artifactId><version>${redis.spring.version}</version></dependency>
完整pom.xml
<?xml version="1.0" encoding="UTF-8"?><project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd"><modelVersion>4.0.0</modelVersion><groupId>com.wxm</groupId><artifactId>ssm</artifactId><version>1.0-SNAPSHOT</version><packaging>war</packaging><name>ssm Maven Webapp</name><!-- FIXME change it to the project's website --><url>http://www.example.com</url><properties><project.build.sourceEncoding>UTF-8</project.build.sourceEncoding><maven.compiler.source>1.7</maven.compiler.source><maven.compiler.target>1.7</maven.compiler.target><maven.compiler.plugin.version>3.7.0</maven.compiler.plugin.version><!--添加jar包依赖--><!--文件上传--><commons-fileupload.version>1.3.3</commons-fileupload.version><!--1.spring 5.0.2.RELEASE相关--><spring.version>5.0.2.RELEASE</spring.version><!--2.mybatis相关--><mybatis.version>3.4.5</mybatis.version><!--mysql--><mysql.version>5.1.44</mysql.version><!--pagehelper分页jar依赖--><pagehelper.version>5.1.2</pagehelper.version><!--mybatis与spring集成jar依赖--><mybatis.spring.version>1.3.1</mybatis.spring.version><!--3.dbcp2连接池相关 druid--><commons.dbcp2.version>2.1.1</commons.dbcp2.version><commons.pool2.version>2.4.3</commons.pool2.version><!--4.log日志相关--><log4j2.version>2.9.1</log4j2.version><log4j2.disruptor.version>3.2.0</log4j2.disruptor.version><slf4j.version>1.7.13</slf4j.version><!-- redis与spring的整合依赖 --><redis.version>2.9.0</redis.version><redis.spring.version>1.7.1.RELEASE</redis.spring.version><!-- jackson --><jackson.version>2.9.3</jackson.version><!--5.其他--><junit.version>4.12</junit.version><servlet.version>4.0.0</servlet.version><lombok.version>1.18.2</lombok.version><tomcat-jsp-api.version>8.0.47</tomcat-jsp-api.version></properties><dependencies><dependency><groupId>org.apache.shiro</groupId><artifactId>shiro-core</artifactId><version>1.3.2</version></dependency><dependency><groupId>org.apache.shiro</groupId><artifactId>shiro-web</artifactId><version>1.3.2</version></dependency><dependency><groupId>org.apache.shiro</groupId><artifactId>shiro-spring</artifactId><version>1.3.2</version></dependency><!--引入JWT依赖,由于是基于Java，所以需要的是java-jwt --><dependency><groupId>io.jsonwebtoken</groupId><artifactId>jjwt</artifactId><version>0.9.1</version></dependency><dependency><groupId>com.auth0</groupId><artifactId>java-jwt</artifactId><version>3.4.0</version></dependency><!--文件上传--><dependency><groupId>commons-fileupload</groupId><artifactId>commons-fileupload</artifactId><version>1.3.3</version></dependency><!--1.spring相关--><dependency><groupId>org.springframework</groupId><artifactId>spring-core</artifactId><version>${spring.version}</version></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-beans</artifactId><version>${spring.version}</version></dependency><!--这是引入springframework 这个项目中的web模块--><dependency><groupId>org.springframework</groupId><artifactId>spring-webmvc</artifactId><version>${spring.version}</version></dependency><dependency><groupId>jstl</groupId><artifactId>jstl</artifactId><version>1.2</version></dependency><dependency><groupId>taglibs</groupId><artifactId>standard</artifactId><version>1.1.2</version></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-orm</artifactId><version>${spring.version}</version></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-tx</artifactId><version>${spring.version}</version></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-aspects</artifactId><version>${spring.version}</version></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-web</artifactId><version>${spring.version}</version></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-test</artifactId><version>${spring.version}</version></dependency><!--2.mybatis相关--><dependency><groupId>org.mybatis</groupId><artifactId>mybatis</artifactId><version>${mybatis.version}</version></dependency><!--mysql--><dependency><groupId>mysql</groupId><artifactId>mysql-connector-java</artifactId><version>${mysql.version}</version></dependency><!--pagehelper分页插件jar包依赖--><dependency><groupId>com.github.pagehelper</groupId><artifactId>pagehelper</artifactId><version>${pagehelper.version}</version></dependency><!--mybatis与spring集成jar包依赖--><dependency><groupId>org.mybatis</groupId><artifactId>mybatis-spring</artifactId><version>${mybatis.spring.version}</version></dependency><!--3.dbcp2连接池相关--><dependency><groupId>org.apache.commons</groupId><artifactId>commons-dbcp2</artifactId><version>${commons.dbcp2.version}</version></dependency><dependency><groupId>org.apache.commons</groupId><artifactId>commons-pool2</artifactId><version>${commons.pool2.version}</version></dependency><!--4.log日志相关依赖--><!--核心log4j2jar包--><dependency><groupId>org.apache.logging.log4j</groupId><artifactId>log4j-core</artifactId><version>${log4j2.version}</version></dependency><dependency><groupId>org.apache.logging.log4j</groupId><artifactId>log4j-api</artifactId><version>${log4j2.version}</version></dependency><!--web工程需要包含log4j-web，非web工程不需要--><dependency><groupId>org.apache.logging.log4j</groupId><artifactId>log4j-web</artifactId><version>${log4j2.version}</version></dependency><!--5.其他--><dependency><groupId>junit</groupId><artifactId>junit</artifactId><version>${junit.version}</version><scope>test</scope></dependency><dependency><groupId>javax.servlet</groupId><artifactId>javax.servlet-api</artifactId><version>${servlet.version}</version><scope>provided</scope></dependency><dependency><groupId>org.projectlombok</groupId><artifactId>lombok</artifactId><version>${lombok.version}</version><scope>provided</scope></dependency><dependency><groupId>org.springframework</groupId><artifactId>spring-context-support</artifactId><version>${spring.version}</version></dependency><!--mybatis与ehcache整合--><dependency><groupId>org.mybatis.caches</groupId><artifactId>mybatis-ehcache</artifactId><version>1.1.0</version></dependency><!--ehcache依赖--><dependency><groupId>net.sf.ehcache</groupId><artifactId>ehcache</artifactId><version>2.10.0</version></dependency><!-- log4j2日志相关依赖 --><!-- log配置：Log4j2 + Slf4j --><!-- slf4j核心包--><dependency><groupId>org.slf4j</groupId><artifactId>slf4j-api</artifactId><version>${slf4j.version}</version></dependency><dependency><groupId>org.slf4j</groupId><artifactId>jcl-over-slf4j</artifactId><version>${slf4j.version}</version><scope>runtime</scope></dependency><!--核心log4j2jar包--><dependency><groupId>org.apache.logging.log4j</groupId><artifactId>log4j-api</artifactId><version>${log4j2.version}</version></dependency><dependency><groupId>org.apache.logging.log4j</groupId><artifactId>log4j-core</artifactId><version>${log4j2.version}</version></dependency><!--用于与slf4j保持桥接--><dependency><groupId>org.apache.logging.log4j</groupId><artifactId>log4j-slf4j-impl</artifactId><version>${log4j2.version}</version></dependency><!--web工程需要包含log4j-web，非web工程不需要--><dependency><groupId>org.apache.logging.log4j</groupId><artifactId>log4j-web</artifactId><version>${log4j2.version}</version><scope>runtime</scope></dependency><!--需要使用log4j2的AsyncLogger需要包含disruptor--><dependency><groupId>com.lmax</groupId><artifactId>disruptor</artifactId><version>${log4j2.disruptor.version}</version></dependency><dependency><groupId>redis.clients</groupId><artifactId>jedis</artifactId><version>${redis.version}</version></dependency><dependency><groupId>org.springframework.data</groupId><artifactId>spring-data-redis</artifactId><version>${redis.spring.version}</version></dependency><!-- jackson --><dependency><groupId>com.fasterxml.jackson.core</groupId><artifactId>jackson-databind</artifactId><version>${jackson.version}</version></dependency><dependency><groupId>com.fasterxml.jackson.core</groupId><artifactId>jackson-core</artifactId><version>${jackson.version}</version></dependency><dependency><groupId>com.fasterxml.jackson.core</groupId><artifactId>jackson-annotations</artifactId><version>${jackson.version}</version></dependency><dependency><groupId>org.apache.tomcat</groupId><artifactId>tomcat-jsp-api</artifactId><version>${tomcat-jsp-api.version}</version></dependency></dependencies><build><finalName>ssm</finalName><resources><!--解决mybatis-generator-maven-plugin运行时没有将XxxMapper.xml文件放入target文件夹的问题--><resource><directory>src/main/java</directory><includes><include>**/*.xml</include></includes></resource><!--解决mybatis-generator-maven-plugin运行时没有将jdbc.properites文件放入target文件夹的问题--><resource><directory>src/main/resources</directory><includes><include>*.properties</include><include>*.xml</include></includes></resource></resources><pluginManagement><plugins><plugin><groupId>org.apache.maven.plugins</groupId><artifactId>maven-compiler-plugin</artifactId><version>${maven.compiler.plugin.version}</version><configuration><source>${maven.compiler.source}</source><target>${maven.compiler.target}</target><encoding>${project.build.sourceEncoding}</encoding></configuration></plugin><plugin><groupId>org.mybatis.generator</groupId><artifactId>mybatis-generator-maven-plugin</artifactId><version>1.3.2</version><dependencies><!--使用Mybatis-generator插件不能使用太高版本的mysql驱动 --><dependency><groupId>mysql</groupId><artifactId>mysql-connector-java</artifactId><version>${mysql.version}</version></dependency></dependencies><configuration><overwrite>true</overwrite></configuration></plugin></plugins></pluginManagement></build>
</project>redis.properties
redis.hostName=192.168.192.131
redis.port=6379
redis.password=123456
redis.timeout=10000
redis.maxIdle=300
redis.maxTotal=1000
redis.maxWaitMillis=1000
redis.minEvictableIdleTimeMillis=300000
redis.numTestsPerEvictionRun=1024
redis.timeBetweenEvictionRunsMillis=30000
redis.testOnBorrow=true
redis.testWhileIdle=true完整web.xml
<web-app xmlns="http://xmlns.jcp.org/xml/ns/javaee"xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"xsi:schemaLocation="http://xmlns.jcp.org/xml/ns/javaee http://xmlns.jcp.org/xml/ns/javaee/web-app_3_1.xsd"version="3.1"><display-name>Archetype Created Web Application</display-name><context-param><param-name>contextConfigLocation</param-name><param-value>classpath:applicationContext.xml</param-value></context-param><!-- shiro过滤器定义 --><filter><filter-name>shiroFilter</filter-name><filter-class>org.springframework.web.filter.DelegatingFilterProxy</filter-class><init-param><!-- 该值缺省为false,表示生命周期由SpringApplicationContext管理,设置为true则表示由ServletContainer管理 --><param-name>targetFilterLifecycle</param-name><param-value>true</param-value></init-param></filter><filter-mapping><filter-name>shiroFilter</filter-name><url-pattern>/*</url-pattern></filter-mapping><!-- 读取Spring上下文的监听器 --><listener><listener-class>org.springframework.web.context.ContextLoaderListener</listener-class></listener><!-- 解决cors跨域问题过滤器 --><filter><filter-name>corsFilter</filter-name><filter-class>com.wxm.util.CorsFilter</filter-class></filter><filter-mapping><filter-name>corsFilter</filter-name><url-pattern>/*</url-pattern></filter-mapping><!-- 解决jwt问题的过滤器 --><filter><filter-name>jwtFilter</filter-name><filter-class>com.wxm.util.JwtFilter</filter-class></filter><filter-mapping><filter-name>jwtFilter</filter-name><url-pattern>/*</url-pattern></filter-mapping><!--解决乱码 --><filter><filter-name>encodingFiter</filter-name><filter-class>com.wxm.util.EncodingFiter</filter-class></filter><filter-mapping><filter-name>encodingFiter</filter-name><url-pattern>/*</url-pattern></filter-mapping><!-- Spring MVC servlet --><servlet><servlet-name>SpringMVC</servlet-name><servlet-class>org.springframework.web.servlet.DispatcherServlet</servlet-class><!--此参数可以不配置，默认值为：/WEB-INF/springmvc-servlet.xml--><init-param><param-name>contextConfigLocation</param-name><param-value>classpath:springmvc-servlet.xml</param-value></init-param><load-on-startup>1</load-on-startup><!--web.xml 3.0的新特性，是否支持异步--><async-supported>true</async-supported></servlet><servlet-mapping><servlet-name>SpringMVC</servlet-name><url-pattern>/</url-pattern></servlet-mapping>
</web-app>JwtFilter
package com.wxm.util;import javax.servlet.*;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import java.io.IOException;
import java.util.regex.Matcher;
import java.util.regex.Pattern;
import io.jsonwebtoken.Claims;
/*** JWT验证过滤器，配置顺序 ：CorsFilte-->JwtFilter-->control层* @author wxm* @site www.wxm.com* @company xxx公司* @create 2019-11-25 16:31*/
public class JwtFilter implements Filter {// 排除的URL，一般为登陆的URL(请改成自己登陆的URL)private static String EXCLUDE = "^/vue/userAction_login\\.action?.*$";private static Pattern PATTERN = Pattern.compile(EXCLUDE);private boolean OFF =false ;// true关闭jwt令牌验证功能@Overridepublic void init(FilterConfig filterConfig) throws ServletException {}@Overridepublic void destroy() {}@Overridepublic void doFilter(ServletRequest request, ServletResponse response, FilterChain chain) throws IOException, ServletException {HttpServletRequest req = (HttpServletRequest) request;HttpServletResponse resp = (HttpServletResponse) response;String path = req.getServletPath();if (OFF || isExcludeUrl(path)) {// 登陆直接放行chain.doFilter(request, response);return;}// 从客户端请求头中获得令牌并验证String jwt = req.getHeader(JwtUtils.JWT_HEADER_KEY);Claims claims = this.validateJwtToken(jwt);if (null == claims) {// resp.setCharacterEncoding("UTF-8");resp.sendError(403, "JWT令牌已过期或已失效");return;} else {String newJwt = JwtUtils.copyJwt(jwt, JwtUtils.JWT_WEB_TTL);resp.setHeader(JwtUtils.JWT_HEADER_KEY, newJwt);chain.doFilter(request, response);}}/*** 验证jwt令牌，验证通过返回声明(包括公有和私有)，返回null则表示验证失败*/private Claims validateJwtToken(String jwt) {Claims claims = null;try {if (null != jwt) {claims = JwtUtils.parseJwt(jwt);}} catch (Exception e) {e.printStackTrace();}return claims;}/*** 是否为排除的URL** @param path* @return*/private boolean isExcludeUrl(String path) {Matcher matcher = PATTERN.matcher(path);return matcher.matches();}public static void main(String[] args) {String path = "/vue/user/login?username=zs&password=123";Matcher matcher = PATTERN.matcher(path);boolean b = matcher.matches();System.out.println(b);}}
JSONResult
package com.wxm.util;/*** @author wxm* @site www.wxm.com* @company xxx公司* @create 2019-11-25 17:11*/
public class JSONResult {// 响应业务状态private Integer status;// 响应消息private String msg;// 响应中的数据private Object data;private String ok; // 不使用public static JSONResult build(Integer status, String msg, Object data) {return new JSONResult(status, msg, data);}public static JSONResult ok(Object data) {return new JSONResult(data);}public static JSONResult ok() {return new JSONResult(null);}public static JSONResult errorMsg(String msg) {return new JSONResult(500, msg, null);}public static JSONResult errorMap(Object data) {return new JSONResult(501, "error", data);}public static JSONResult errorTokenMsg(String msg) {return new JSONResult(502, msg, null);}public static JSONResult errorException(String msg) {return new JSONResult(555, msg, null);}public JSONResult() {}public JSONResult(Integer status, String msg, Object data) {this.status = status;this.msg = msg;this.data = data;}public JSONResult(Object data) {this.status = 200;this.msg = "OK";this.data = data;}public Boolean isOK() {return this.status == 200;}public Integer getStatus() {return status;}public void setStatus(Integer status) {this.status = status;}public String getMsg() {return msg;}public void setMsg(String msg) {this.msg = msg;}public Object getData() {return data;}public void setData(Object data) {this.data = data;}public String getOk() {return ok;}public void setOk(String ok) {this.ok = ok;}}
ImageUtil
package com.wxm.util;import sun.misc.BASE64Encoder;import javax.imageio.ImageIO;
import java.awt.*;
import java.awt.image.BufferedImage;
import java.io.ByteArrayOutputStream;
import java.io.IOException;
import java.util.Random;
import sun.misc.BASE64Encoder;import javax.imageio.ImageIO;
import java.awt.*;
import java.awt.image.BufferedImage;
import java.io.ByteArrayOutputStream;
import java.io.IOException;
import java.util.Random;public class ImageUtil {/*** 根据指定的随机数 生成验证码图片 转 base64* @param word 要生存的验证码随机字符串* @param width 图片宽度* @param height 图片高度* @return base64 格式生成的验证码图片* @throws IOException*/public static String createImageWithVerifyCode(String word, int width, int height) throws IOException {String png_base64="";//绘制内存中的图片BufferedImage bufferedImage = new BufferedImage(width,height,BufferedImage.TYPE_INT_RGB);//得到画图对象Graphics graphics = bufferedImage.getGraphics();//绘制图片前指定一个颜色graphics.setColor(getRandColor(160,200));graphics.fillRect(0,0,width,height);//绘制边框graphics.setColor(Color.white);graphics.drawRect(0, 0, width - 1, height - 1);// 步骤四 四个随机数字Graphics2D graphics2d = (Graphics2D) graphics;graphics2d.setFont(new Font("宋体", Font.BOLD, 18));Random random = new Random();// 定义x坐标int x = 10;for (int i = 0; i < word.length(); i++) {// 随机颜色graphics2d.setColor(new Color(20 + random.nextInt(110), 20 + random.nextInt(110), 20 + random.nextInt(110)));// 旋转 -30 --- 30度int jiaodu = random.nextInt(60) - 30;// 换算弧度double theta = jiaodu * Math.PI / 180;// 获得字母数字char c = word.charAt(i);//将c 输出到图片graphics2d.rotate(theta, x, 20);graphics2d.drawString(String.valueOf(c), x, 20);graphics2d.rotate(-theta, x, 20);x += 30;}// 绘制干扰线graphics.setColor(getRandColor(160, 200));int x1;int x2;int y1;int y2;for (int i = 0; i < 30; i++) {x1 = random.nextInt(width);x2 = random.nextInt(12);y1 = random.nextInt(height);y2 = random.nextInt(12);graphics.drawLine(x1, y1, x1 + x2, x2 + y2);}graphics.dispose();// 释放资源ByteArrayOutputStream baos = new ByteArrayOutputStream();//io流ImageIO.write(bufferedImage, "png", baos);//写入流中byte[] bytes = baos.toByteArray();//转换成字节BASE64Encoder encoder = new BASE64Encoder();png_base64 = encoder.encodeBuffer(bytes).trim();png_base64 = png_base64.replaceAll("\n", "").replaceAll("\r", "");//删除 \r\nreturn png_base64;}/**设置随机颜色*/private static Color getRandColor(int fc, int bc) {// 取其随机颜色Random random = new Random();if (fc > 255) {fc = 255;}if (bc > 255) {bc = 255;}int r = fc + random.nextInt(bc - fc);int g = fc + random.nextInt(bc - fc);int b = fc + random.nextInt(bc - fc);return new Color(r, g, b);}}
CorsFilter，JwtUtils前面ssh都有
==StringUtils ==
package com.wxm.util;/*** @author wxm* @site www.wxm.com* @company xxx公司* @create 2019-11-22 11:09*/
public class StringUtils {// 私有的构造方法，保护此类不能在外部实例化private StringUtils() {}/*** 如果字符串等于null或去空格后等于""，则返回true，否则返回false** @param s* @return*/public static boolean isBlank(String s) {boolean b = false;if (null == s || s.trim().equals("")) {b = true;}return b;}/*** 如果字符串不等于null或去空格后不等于""，则返回true，否则返回false** @param s* @return*/public static boolean isNotBlank(String s) {return !isBlank(s);}}UserMapper.java
User login(User user);
UserMapper.xml
<select id="login" resultType="com.wxm.model.User" parameterType="com.wxm.model.User">select<include refid="Base_Column_List" />from t_vue_userwhere uname = #{uname} and pwd = #{pwd}</select>
UserService,Impl省略
User login(User user);
==UserController ==
package com.wxm.controller;import com.auth0.jwt.JWT;
import com.auth0.jwt.interfaces.Claim;
import com.wxm.model.User;
import com.wxm.service.UserService;
import com.wxm.util.ImageUtil;
import com.wxm.util.JSONResult;
import com.wxm.util.JwtUtils;
import com.wxm.util.VerifyCodeUtil;
import io.jsonwebtoken.Claims;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Controller;
import org.springframework.util.StringUtils;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import sun.misc.Request;
import org.springframework.data.redis.core.RedisTemplate;import javax.annotation.Resource;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;
import java.io.IOException;
import java.util.HashMap;
import java.util.Map;
import java.util.concurrent.TimeUnit;/*** @author wxm* @site www.wxm.com* @company xxx公司* @create 2019-11-25 18:55*/@Controller
@RequestMapping("/vue/user")
public class UserController {private static final String VERIFICATION_CODE = "verificationCode_";@Autowiredprivate UserService userService;@Autowiredprivate RedisTemplate redisTemplate;@RequestMapping("/login")@ResponseBodypublic JSONResult login(User u, HttpServletRequest request, HttpServletResponse response){//获取用户输入的验证码String userVerificationCode = request.getParameter("verificationCode");//获取验证码jwt令牌String userJwt = request.getHeader(JwtUtils.JWT_VERIFICATION_KEY);//获取到保存在redis中的验证码Object redisVerificationCode = redisTemplate.opsForValue().get(VERIFICATION_CODE + userJwt) ;// 这里存在两种情况：1、令牌超时 2、验证码超时if(StringUtils.isEmpty(redisVerificationCode)){return JSONResult.errorMsg("你的验证码已超时");}if(!redisVerificationCode.toString().equalsIgnoreCase(userVerificationCode)){return JSONResult.errorMsg("验证码错误");}User user = userService.login(u);//判断是否登录成功if(user != null){Map<String,Object> map=new HashMap<String, Object>();map.put("User", user);//这是颁发用户登录成功的jwt令牌String jwt= JwtUtils.createJwt(map, JwtUtils.JWT_WEB_TTL);response.setHeader(JwtUtils.JWT_HEADER_KEY, jwt);return JSONResult.ok(user);}else {return JSONResult.errorMsg("密码或账户错误");}}/**生成图片验证码*/@RequestMapping("/verificationCode")@ResponseBodypublic String verificationCode(HttpServletRequest req, HttpServletResponse resp) throws IOException {//生成验证码随机数String word = VerifyCodeUtil.produceNumAndChar(4);
}
验证码效果：
登录成功：
SSH
思路：
1. 从后端随机生成验证码，存储到redis里面，同时发送到前台（在进入登录界面的时候）
2. 前台把验证码展示出来，在提交表单时，把用户输入的验证码作为参数传输。
3. 后端接收到前台传过来的验证码，同时从redis拿值相对比，就能判断是否正确。
测试redis是否连接成功
redis连接成功！！！
详细代码
后端
相关代码参考jwt
CorsFilter
package com.zking.vue.util;import java.io.IOException;import javax.servlet.Filter;
import javax.servlet.FilterChain;
import javax.servlet.FilterConfig;
import javax.servlet.ServletException;
import javax.servlet.ServletRequest;
import javax.servlet.ServletResponse;
import javax.servlet.http.HttpServletRequest;
import javax.servlet.http.HttpServletResponse;/*** 配置tomcat允许跨域访问* * @author Administrator**/
public class CorsFilter implements Filter {@Overridepublic void init(FilterConfig filterConfig) throws ServletException {}// @Override// public void doFilter(ServletRequest servletRequest, ServletResponse// servletResponse, FilterChain filterChain)// throws IOException, ServletException {// HttpServletResponse httpResponse = (HttpServletResponse) servletResponse;//// // Access-Control-Allow-Origin就是我们需要设置的域名// // Access-Control-Allow-Headers跨域允许包含的头。// // Access-Control-Allow-Methods是允许的请求方式// httpResponse.addHeader("Access-Control-Allow-Origin", "*");// *,任何域名// httpResponse.setHeader("Access-Control-Allow-Methods", "POST, GET, PUT,// DELETE");// // httpResponse.setHeader("Access-Control-Allow-Headers", "Origin,// // X-Requested-With, Content-Type, Accept");//// // 允许请求头Token// httpResponse.setHeader("Access-Control-Allow-Headers",// "Origin,X-Requested-With, Content-Type, Accept, Token");// HttpServletRequest req = (HttpServletRequest) servletRequest;// System.out.println("Token=" + req.getHeader("Token"));// if("OPTIONS".equals(req.getMethod())) {// return;// }////// filterChain.doFilter(servletRequest, servletResponse);// }@Overridepublic void doFilter(ServletRequest servletRequest, ServletResponse servletResponse, FilterChain filterChain)throws IOException, ServletException {HttpServletResponse resp = (HttpServletResponse) servletResponse;HttpServletRequest req = (HttpServletRequest) servletRequest;// Access-Control-Allow-Origin就是我们需要设置的域名// Access-Control-Allow-Headers跨域允许包含的头。// Access-Control-Allow-Methods是允许的请求方式resp.setHeader("Access-Control-Allow-Origin", "*");// *,任何域名resp.setHeader("Access-Control-Allow-Methods", "POST, GET, PUT, DELETE");// resp.setHeader("Access-Control-Allow-Headers", "Origin,X-Requested-With,// Content-Type, Accept");// 允许客户端，发一个新的请求头jwtresp.setHeader("Access-Control-Allow-Headers", "Origin,X-Requested-With, Content-Type, Accept, jwt");// 允许客户端，处理一个新的响应头jwtresp.setHeader("Access-Control-Expose-Headers", "jwt");// String sss = resp.getHeader("Access-Control-Expose-Headers");// System.out.println("sss=" + sss);// 允许请求头Token// httpResponse.setHeader("Access-Control-Allow-Headers","Origin,X-Requested-With,// Content-Type, Accept, Token");// System.out.println("Token=" + req.getHeader("Token"));if ("OPTIONS".equals(req.getMethod())) {// axios的ajax会发两次请求，第一次提交方式为：option，直接返回即可return;}filterChain.doFilter(servletRequest, servletResponse);}@Overridepublic void destroy() {}
}
JwtUtils
package com.zking.vue.util;import java.util.Date;
import java.util.Map;
import java.util.UUID;import javax.crypto.SecretKey;
import javax.crypto.spec.SecretKeySpec;import org.apache.commons.codec.binary.Base64;import io.jsonwebtoken.Claims;
import io.jsonwebtoken.JwtBuilder;
import io.jsonwebtoken.Jwts;
import io.jsonwebtoken.SignatureAlgorithm;/*** JWT验证过滤器：配置顺序 CorsFilte->JwtUtilsr-->StrutsPrepareAndExecuteFilter**/
public class JwtUtils {/*** JWT_WEB_TTL：WEBAPP应用中token的有效时间,默认30分钟*/public static final long JWT_WEB_TTL = 30 * 60 * 1000;/*** 将jwt令牌保存到header中的key*/public static final String JWT_HEADER_KEY = "jwt";// 指定签名的时候使用的签名算法，也就是header那部分，jjwt已经将这部分内容封装好了。private static final SignatureAlgorithm SIGNATURE_ALGORITHM = SignatureAlgorithm.HS256;private static final String JWT_SECRET = "f356cdce935c42328ad2001d7e9552a3";// JWT密匙private static final SecretKey JWT_KEY;// 使用JWT密匙生成的加密keystatic {byte[] encodedKey = Base64.decodeBase64(JWT_SECRET);JWT_KEY = new SecretKeySpec(encodedKey, 0, encodedKey.length, "AES");}private JwtUtils() {}/*** 解密jwt，获得所有声明(包括标准和私有声明)* * @param jwt* @return* @throws Exception*/public static Claims parseJwt(String jwt) {Claims claims = Jwts.parser().setSigningKey(JWT_KEY).parseClaimsJws(jwt).getBody();return claims;}/*** 创建JWT令牌，签发时间为当前时间* * @param claims* 创建payload的私有声明（根据特定的业务需要添加，如果要拿这个做验证，一般是需要和jwt的接收方提前沟通好验证方式的）* @param ttlMillis* JWT的有效时间(单位毫秒)，当前时间+有效时间=过期时间* @return jwt令牌*/public static String createJwt(Map<String, Object> claims, long ttlMillis) {// 生成JWT的时间，即签发时间long nowMillis = System.currentTimeMillis();// 下面就是在为payload添加各种标准声明和私有声明了// 这里其实就是new一个JwtBuilder，设置jwt的bodyJwtBuilder builder = Jwts.builder()// 如果有私有声明，一定要先设置这个自己创建的私有的声明，这个是给builder的claim赋值，一旦写在标准的声明赋值之后，就是覆盖了那些标准的声明的.setClaims(claims)// 设置jti(JWT ID)：是JWT的唯一标识，根据业务需要，这个可以设置为一个不重复的值，主要用来作为一次性token,从而回避重放攻击。// 可以在未登陆前作为身份标识使用.setId(UUID.randomUUID().toString().replace("-", ""))// iss(Issuser)签发者，写死// .setIssuer("zking")// iat: jwt的签发时间.setIssuedAt(new Date(nowMillis))// 代表这个JWT的主体，即它的所有人，这个是一个json格式的字符串，可放数据{"uid":"zs"}。此处没放// .setSubject("{}")// 设置签名使用的签名算法和签名使用的秘钥.signWith(SIGNATURE_ALGORITHM, JWT_KEY)// 设置JWT的过期时间.setExpiration(new Date(nowMillis + ttlMillis));return builder.compact();}/*** 复制jwt，并重新设置签发时间(为当前时间)和失效时间* * @param jwt* 被复制的jwt令牌* @param ttlMillis* jwt的有效时间(单位毫秒)，当前时间+有效时间=过期时间* @return*/public static String copyJwt(String jwt, Long ttlMillis) {Claims claims = parseJwt(jwt);// 生成JWT的时间，即签发时间long nowMillis = System.currentTimeMillis();// 下面就是在为payload添加各种标准声明和私有声明了// 这里其实就是new一个JwtBuilder，设置jwt的bodyJwtBuilder builder = Jwts.builder()// 如果有私有声明，一定要先设置这个自己创建的私有的声明，这个是给builder的claim赋值，一旦写在标准的声明赋值之后，就是覆盖了那些标准的声明的.setClaims(claims)// 设置jti(JWT ID)：是JWT的唯一标识，根据业务需要，这个可以设置为一个不重复的值，主要用来作为一次性token,从而回避重放攻击。// 可以在未登陆前作为身份标识使用
// .setId(UUID.randomUUID().toString().replace("-", ""))// iss(Issuser)签发者，写死// .setIssuer("zking")// iat: jwt的签发时间.setIssuedAt(new Date(nowMillis))// 代表这个JWT的主体，即它的所有人，这个是一个json格式的字符串，可放数据{"uid":"zs"}。此处没放// .setSubject("{}")// 设置签名使用的签名算法和签名使用的秘钥.signWith(SIGNATURE_ALGORITHM, JWT_KEY)// 设置JWT的过期时间.setExpiration(new Date(nowMillis + ttlMillis));return builder.compact();}
}pom.xml
<dependency><groupId>redis.clients</groupId><artifactId>jedis</artifactId><version>2.9.0</version></dependency>
UserAction
package com.zking.vue.web;import java.util.HashMap;
import java.util.Map;
import java.util.Random;import com.fasterxml.jackson.databind.ObjectMapper;
import com.opensymphony.xwork2.ModelDriven;
import com.zking.base.web.BaseAction;
import com.zking.vue.biz.UserBiz;
import com.zking.vue.entity.User;
import com.zking.vue.util.JsonData;
import com.zking.vue.util.JwtUtils;
import com.zking.vue.util.PageBean;
import com.zking.vue.util.ResponseUtil;
import com.zking.vue.util.StringUtils;
import redis.clients.jedis.Jedis;
public class UserAction extends BaseAction implements ModelDriven<User>{private UserBiz userBiz;private User user = new User();public UserBiz getUserBiz() {return userBiz;}public void setUserBiz(UserBiz userBiz) {this.userBiz = userBiz;}
private static Jedis jedis;static {jedis = new Jedis("192.168.192.130", 6379);jedis.auth("123456");//权限认证System.out.println(jedis.ping());}public String login() {ObjectMapper om = new ObjectMapper();JsonData jsonData = null;try {String verificationCode=request.getParameter("verificationCode");//从redis里面拿值String code=jedis.get("code");System.out.println("输入的验证码："+verificationCode);System.out.println("redis的验证码："+code);if(StringUtils.isBlank(user.getUname()) || StringUtils.isBlank(user.getPwd())) {jsonData = new JsonData(0, "用户或者密码为空", user);}else if(!code.equals(verificationCode)|| verificationCode==null ){jsonData = new JsonData(0, "验证码错误或为空", user);} else {User u = this.userBiz.login(user);Map<String, Object> claims = new HashMap<String, Object>();claims.put("uname",user.getUname());claims.put("pwd", user.getPwd());String jwt = JwtUtils.createJwt(claims, JwtUtils.JWT_WEB_TTL);response.setHeader(JwtUtils.JWT_HEADER_KEY, jwt);jsonData = new JsonData(1, "登录成功", u);}} catch (Exception e) {e.printStackTrace();jsonData = new JsonData(0, "用户或者密码错误", user);}finally {try {ResponseUtil.write(response, om.writeValueAsString(jsonData));} catch (Exception e) {e.printStackTrace();}}return null;}/*** 生成随机数* @return*/public String userCode() {Random ra = new Random();String sCode = "A,B,C,E,F,G,H,J,K,L,M,N,P,Q,R,S,T,W,X,Y,Z,1,2,3,4,5,6,7,8,9,0";String[] split = sCode.split(",");String sb = new String();for (int i = 0; i < 4; i++) {System.out.println(ra.nextInt(30));sb+=(split[ra.nextInt(30)]);}ObjectMapper om = new ObjectMapper();JsonData jsonData = null;try {jsonData = new JsonData(0, sb, user);ResponseUtil.write(response, om.writeValueAsString(jsonData));} catch (Exception e) {System.out.println(e);}//把验证码放到Redis缓存里jedis.set("code", sb);return null;}public static void main(String[] args) {UserAction us = new UserAction();us.userCode();}@Overridepublic User getModel() {return user;}
}前台
需要改动api/action.js，和login.vue
Login.vue
<template><div class="login-wrap"><el-form :model="ruleForm" label-width="100px" class="demo-ruleForm login-container"><h3 style="text-align: center;">用户登录</h3><el-form-item label="用户名"><el-input type="text" v-model="ruleForm.uname"></el-input></el-form-item><el-form-item label="密码"><el-input type="password" v-model="ruleForm.pwd"></el-input></el-form-item><el-form-item label="验证码"><el-row><el-col :span="16"><el-input type="text" v-model="ruleForm.verificationCode" placeholder="请输入验证码"></el-input></el-col><el-col :span="8"><!-- {{code}} --><img id="img" :src="ruleForm.verificationCodeSrc" width="116px" height="40px" @click="changeVerificationCode"></el-col></el-row></el-form-item><el-form-item label=""><el-row><el-col :span="24"><div class="grid-content bg-purple-dark"><el-button type="primary" style="width:100%;" @click="doLogin">提交</el-button></div></el-col></el-row><el-row><!-- 添加一个事件事件对应方法 --><el-col :span="12"><div class="grid-content bg-purple-dark"><el-link type="success" @click="toReg">用户注册</el-link></div></el-col><el-col :span="12"><div class="grid-content bg-purple-dark"><el-link type="success">忘记密码</el-link></div></el-col></el-row></el-form-item></el-form></div>
</template><script>export default {data() {return {ruleForm: {uname: 'zs',pwd: '123',verificationCode: '',verificationCodeSrc: '',},code: null,};},methods: {//添加方法toReg() {this.$router.push({path: '/Reg'});},doLogin() {let url = this.axios.urls.SYSTEM_USER_DOLOGIN;console.log(url)// var methis=this;this.axios.post(url, this.ruleForm).then(resp => {console.log(resp);// if (resp.data.code == 1) {//ssh登录if (resp.data.status == 200) { //ssm登录this.$message({message: resp.data.msg,type: 'success'});alert("111")this.$router.push({path: '/AppMain'});//这是将用户信息保持下来// let user=resp.data.data// this.$store.dispatch('setUserAsync',{// user:user// });} else {this.$message({message: resp.data.msg,type: 'warning'});}}).catch(resp => {this.$message({message: "请求异常",type: 'error'});});},//更新验证码changeVerificationCode() {let url = this.axios.urls.VERIFICATION;this.axios.post(url, {}).then(resp => {this.verificationCodeSrc = resp.data;// this.code = resp.data.msg;}).catch(resp => {console.log(resp);});}},created() {//加载验证码let url = this.axios.urls.VERIFICATION;console.log(url)this.axios.post(url, {}).then(resp => {console.log("验证码：" + resp)// this.code = resp.data.msg;//sshthis.ruleForm.verificationCodeSrc = resp.data;//ssm}).catch(resp => {console.log(resp);});}}
</script><!-- Add "scoped" attribute to limit CSS to this component only -->
</style>redis存储验证码
前台显示：
返回的数据类型
