一、天气以及时间分类

比赛地址： https://www.datafountain.cn/competitions/555

1.赛题背景

在自动驾驶场景中，天气和时间（黎明、早上、下午、黄昏、夜晚）会对传感器的精度造成影响，比如雨天和夜晚会对视觉传感器的精度造成很大的影响。此赛题旨在对拍摄的照片天气和时间进行分类，从而在不同的天气和时间使用不同的自动驾驶策略。

2.赛题任务

此赛题的数据集由云测数据提供。比赛数据集中包含3000张真实场景下行车记录仪采集的图片，其中训练集包含2600张带有天气和时间类别标签的图片，测试集包含400张不带有标签的图片。参赛者需基于Oneflow框架在训练集上进行训练，对测试集中照片的天气和时间进行分类。

3.数据简介

本赛题的数据集包含2600张人工标注的天气和时间标签。

• 天气类别：多云、晴天、雨天、雪天和雾天5个类别
• 时间：黎明、早上、下午、黄昏、夜晚5个类别

下午 多云

早上 雨天

4.数据说明

数据集包含anno和image两个文件夹，anno文件夹中包含2600个标签json文件，image文件夹中包含3000张行车记录仪拍摄的JPEG编码照片。图片标签将字典以json格式序列化进行保存：

5.提交要求

参赛者使用Oneflow框架对数据集进行训练后对测试集图片进行推理后，
1.将测试集图片的目标检测和识别结果以与训练集格式保持一致的json文件序列化保存，并上传至参赛平台由参赛平台自动评测返回结果。
2.在提交时的备注附上自己的模型github仓库链接

6.提交示例

{
“annotations”: [
{
“filename”: “test_images\00008.jpg”,
“period”: “Morning”,
“weather”: “Cloudy”
}]
}

7.解题思路

总体上看，该任务可以分为2个：一个是预测时间、一个是预测天气，具体如下：

• 预测时间、天气数据标签列表生成
• 数据集划分
• 数据均衡（数据很不均衡）
• 分别预测
• 合并预测结果

二、数据集准备

1.数据下载

# 直接下载，速度超快
!wget https://awscdn.datafountain.cn/cometition_data2/Files/BDCI2021/555/train_dataset.zip
!wget https://awscdn.datafountain.cn/cometition_data2/Files/BDCI2021/555/test_dataset.zip
!wget https://awscdn.datafountain.cn/cometition_data2/Files/BDCI2021/555/submit_example.json

2.数据解压缩

# 解压缩数据集
!unzip -qoa test_dataset.zip
!unzip -qoa train_dataset.zip

3.按时间制作标签

注意事项：虽然数据描述说时间** Period 为 黎明、早上、下午、黄昏、夜晚**，但是经过遍历发现只有4类。。。。。，故如下制作标签

# 标签修改
%cd ~
import json
import ostrain = {}
with open('train.json', 'r') as f:train = json.load(f)period_list = {'Dawn': 0, 'Dusk': 1, 'Morning': 2, 'Afternoon': 3}
f_period=open('train_period.txt','w')
for item in train["annotations"]:label = period_list[item['period']] file_name=os.path.join(item['filename'].split('\\')[0], item['filename'].split('\\')[1])f_period.write(file_name +' '+ str(label) +'\n')
f_period.close()
print("写入train_period.txt完成！！！")

/home/aistudio
写入train_period.txt完成！！！

4.数据集划分并数据均衡

# 数据分析
%cd ~
import pandas as pd
from matplotlib import pyplot as plt
%matplotlib inlinedata=pd.read_csv('train_period.txt', header=None, sep=' ')
print(data[1].value_counts())
data[1].value_counts().plot(kind="bar")

/home/aistudio
2    1613
3     829
1     124
0      34
Name: 1, dtype: int64<matplotlib.axes._subplots.AxesSubplot at 0x7feffe438b50>

# 训练集、测试集划分
import pandas as pd
import os
from sklearn.model_selection import train_test_splitdef split_dataset(data_file):# 展示不同的调用方式data = pd.read_csv(data_file, header=None, sep=' ')train_dataset, eval_dataset = train_test_split(data, test_size=0.2, random_state=42)print(f'train dataset len: {train_dataset.size}')print(f'eval dataset len: {eval_dataset.size}')train_filename='train_' + data_file.split('.')[0]+'.txt'eval_filename='eval_' + data_file.split('.')[0]+'.txt'train_dataset.to_csv(train_filename, index=None, header=None, sep=' ')eval_dataset.to_csv(eval_filename, index=None, header=None, sep=' ')data_file='train_period.txt'
split_dataset(data_file)

train dataset len: 4160
eval dataset len: 1040

# pip更新或安装包后需要重启notebook
!pip install -U scikit-learn
# 数据均衡用
!pip install -U imblearn

# 数据均衡
import pandas as pd
from collections import Counter
from imblearn.over_sampling import SMOTE
import numpy as npdef upsampleing(filename):print(50 * '*')data = pd.read_csv(filename, header=None, sep=' ')print(data[1].value_counts())# 查看各个标签的样本量print(Counter(data[1]))print(50 * '*')# 数据均衡X = np.array(data[0].index.tolist()).reshape(-1, 1)y = data[1]ros = SMOTE(random_state=0)X_resampled, y_resampled = ros.fit_resample(X, y)print(Counter(y_resampled))print(len(y_resampled))print(50 * '*')img_list=[]for i in range(len(X_resampled)):img_list.append(data.loc[X_resampled[i]][0].tolist()[0])dict_weather={'0':img_list, '1':y_resampled.values}newdata=pd.DataFrame(dict_weather)print(len(newdata))new_filename=filename.split('.')[0]+'_imblearn'+'.txt'newdata.to_csv(new_filename, header=None, index=None, sep=' ')filename='train_train_period.txt'
upsampleing(filename)
filename='eval_train_period.txt'
upsampleing(filename)

**************************************************
2    1304
3     653
1      95
0      28
Name: 1, dtype: int64
Counter({2: 1304, 3: 653, 1: 95, 0: 28})
**************************************************
Counter({2: 1304, 3: 1304, 1: 1304, 0: 1304})
5216
**************************************************
5216
**************************************************
2    309
3    176
1     29
0      6
Name: 1, dtype: int64
Counter({2: 309, 3: 176, 1: 29, 0: 6})
**************************************************
Counter({2: 309, 3: 309, 1: 309, 0: 309})
1236
**************************************************
1236

5.按天气分制作标签

import json
import ostrain = {}
with open('train.json', 'r') as f:train = json.load(f)weather_list =  {'Cloudy': 0, 'Rainy': 1, 'Sunny': 2}
f_weather=open('train_weather.txt','w')
for item in train["annotations"]:label = weather_list[item['weather']] file_name=os.path.join(item['filename'].split('\\')[0], item['filename'].split('\\')[1])f_weather.write(file_name +' '+ str(label) +'\n')
f_weather.close()
print("写入train_weather.txt完成！！！")

写入train_weather.txt完成！！！

6.数据集划分并均衡

import pandas as pd
from matplotlib import pyplot as pltdata=pd.read_csv('train_weather.txt', header=None, sep=' ')
print(data[1].value_counts())
data[1].value_counts().plot(kind="bar")

0    1119
2     886
1     595
Name: 1, dtype: int64<matplotlib.axes._subplots.AxesSubplot at 0x7feffe82d190>

# 训练集、测试集划分import pandas as pd
import os
from sklearn.model_selection import train_test_splitdef split_dataset(data_file):# 展示不同的调用方式data = pd.read_csv(data_file, header=None, sep=' ')train_dataset, eval_dataset = train_test_split(data, test_size=0.2, random_state=42)print(f'train dataset len: {train_dataset.size}')print(f'eval dataset len: {eval_dataset.size}')train_filename='train_' + data_file.split('.')[0]+'.txt'eval_filename='eval_' + data_file.split('.')[0]+'.txt'train_dataset.to_csv(train_filename, index=None, header=None, sep=' ')eval_dataset.to_csv(eval_filename, index=None, header=None, sep=' ')data_file='train_weather.txt'
split_dataset(data_file)

train dataset len: 4160
eval dataset len: 1040

# 数据均衡
import pandas as pd
from collections import Counter
from imblearn.over_sampling import SMOTE
import numpy as npdef upsampleing(filename):print(50 * '*')data = pd.read_csv(filename, header=None, sep=' ')print(data[1].value_counts())# 查看各个标签的样本量print(Counter(data[1]))print(50 * '*')# 数据均衡X = np.array(data[0].index.tolist()).reshape(-1, 1)y = data[1]ros = SMOTE(random_state=0)X_resampled, y_resampled = ros.fit_resample(X, y)print(Counter(y_resampled))print(len(y_resampled))print(50 * '*')img_list=[]for i in range(len(X_resampled)):img_list.append(data.loc[X_resampled[i]][0].tolist()[0])dict_weather={'0':img_list, '1':y_resampled.values}newdata=pd.DataFrame(dict_weather)print(len(newdata))new_filename=filename.split('.')[0]+'_imblearn'+'.txt'newdata.to_csv(new_filename, header=None, index=None, sep=' ')filename='train_train_weather.txt'
upsampleing(filename)
filename='eval_train_weather.txt'
upsampleing(filename)

**************************************************
0    892
2    715
1    473
Name: 1, dtype: int64
Counter({0: 892, 2: 715, 1: 473})
**************************************************
Counter({0: 892, 2: 892, 1: 892})
2676
**************************************************
2676
**************************************************
0    227
2    171
1    122
Name: 1, dtype: int64
Counter({0: 227, 2: 171, 1: 122})
**************************************************
Counter({0: 227, 2: 227, 1: 227})
681
**************************************************
681

三、环境准备

飞桨图像识别套件PaddleClas是飞桨为工业界和学术界所准备的一个图像识别任务的工具集，助力使用者训练出更好的视觉模型和应用落地。此次计划使用端到端的PaddleClas图像分类套件来快速完成分类。此次使用PaddleClas框架完成比赛。

# git 下载PaddleClas
!git clone https://gitee.com/paddlepaddle/PaddleClas.git --depth=1

fatal: destination path 'PaddleClas' already exists and is not an empty directory.

# 安装
%cd ~/PaddleClas/
!pip install -U pip
!pip install -r requirements.txt
!pip install -e ./
%cd ~

四、模型训练 and 评估

1.时间训练

以 PaddleClas/ppcls/configs/ImageNet/VisionTransformer/ViT_small_patch16_224.yaml 为基础进行修改

# global configs
Global:checkpoints: nullpretrained_model: nulloutput_dir: ./output/device: gpusave_interval: 1eval_during_train: Trueeval_interval: 1epochs: 120print_batch_step: 10use_visualdl: False# used for static mode and model exportimage_shape: [3, 224, 224]save_inference_dir: ./inference# model architecture
Arch:name: ViT_small_patch16_224class_num: 1000# loss function config for traing/eval process
Loss:Train:- CELoss:weight: 1.0Eval:- CELoss:weight: 1.0Optimizer:name: Momentummomentum: 0.9lr:name: Piecewiselearning_rate: 0.1decay_epochs: [30, 60, 90]values: [0.1, 0.01, 0.001, 0.0001]regularizer:name: 'L2'coeff: 0.0001# data loader for train and eval
DataLoader:Train:dataset:name: ImageNetDatasetimage_root: ./dataset/ILSVRC2012/cls_label_path: ./dataset/ILSVRC2012/train_list.txttransform_ops:- DecodeImage:to_rgb: Truechannel_first: False- RandCropImage:size: 224- RandFlipImage:flip_code: 1- NormalizeImage:scale: 1.0/255.0mean: [0.5, 0.5, 0.5]std: [0.5, 0.5, 0.5]order: ''sampler:name: DistributedBatchSamplerbatch_size: 64drop_last: Falseshuffle: Trueloader:num_workers: 4use_shared_memory: TrueEval:dataset: name: ImageNetDatasetimage_root: ./dataset/ILSVRC2012/cls_label_path: ./dataset/ILSVRC2012/val_list.txttransform_ops:- DecodeImage:to_rgb: Truechannel_first: False- ResizeImage:resize_short: 256- CropImage:size: 224- NormalizeImage:scale: 1.0/255.0mean: [0.5, 0.5, 0.5]std: [0.5, 0.5, 0.5]order: ''sampler:name: DistributedBatchSamplerbatch_size: 64drop_last: Falseshuffle: Falseloader:num_workers: 4use_shared_memory: TrueInfer:infer_imgs: docs/images/whl/demo.jpgbatch_size: 10transforms:- DecodeImage:to_rgb: Truechannel_first: False- ResizeImage:resize_short: 256- CropImage:size: 224- NormalizeImage:scale: 1.0/255.0mean: [0.5, 0.5, 0.5]std: [0.5, 0.5, 0.5]order: ''- ToCHWImage:PostProcess:name: Topktopk: 5class_id_map_file: ppcls/utils/imagenet1k_label_list.txtMetric:Train:- TopkAcc:topk: [1, 5]Eval:- TopkAcc:topk: [1, 5]

# 覆盖配置
%cd ~
!cp -f ~/ViT_small_patch16_224.yaml ~/ppcls/configs/ImageNet/VisionTransformer/ViT_small_patch16_224.yaml

/home/aistudio

# 开始训练
%cd ~/PaddleClas/!python3 tools/train.py \-c ./ppcls/configs/ImageNet/VisionTransformer/ViT_base_patch16_224.yaml \-o Arch.pretrained=True \-o Global.pretrained_model=./output/ViT_base_patch16_224/epoch_21 \-o Global.device=gpu

/home/aistudio/PaddleClas

# 模型评估
%cd ~/PaddleClas/!python  tools/eval.py \-c  ./ppcls/configs/ImageNet/VisionTransformer/ViT_base_patch16_224.yaml \-o Global.pretrained_model=./output/ViT_base_patch16_224/best_model

2.天气训练

配置文件为：** PaddleClas/ppcls/configs/ImageNet/VisionTransformer/ViT_base_patch16_224_weather.yaml**

# global configs
Global:checkpoints: nullpretrained_model: nulloutput_dir: ./output_weather/device: gpusave_interval: 1eval_during_train: Trueeval_interval: 1epochs: 120print_batch_step: 10use_visualdl: False# used for static mode and model exportimage_shape: [3, 224, 224]save_inference_dir: ./inference_weather# model architecture
Arch:name: ViT_base_patch16_224class_num: 3# loss function config for traing/eval process
Loss:Train:- CELoss:weight: 1.0Eval:- CELoss:weight: 1.0Optimizer:name: Momentummomentum: 0.9lr:name: Piecewiselearning_rate: 0.01decay_epochs: [10, 22, 30]values: [0.01, 0.001, 0.0001, 0.00001]regularizer:name: 'L2'coeff: 0.0001# data loader for train and eval
DataLoader:Train:dataset:name: ImageNetDatasetimage_root: /home/aistudiocls_label_path: /home/aistudio/train_train_weather_imblearn.txttransform_ops:- DecodeImage:to_rgb: Truechannel_first: False- RandCropImage:size: 224- RandFlipImage:flip_code: 1- NormalizeImage:scale: 1.0/255.0mean: [0.5, 0.5, 0.5]std: [0.5, 0.5, 0.5]order: ''sampler:name: DistributedBatchSamplerbatch_size: 160drop_last: Falseshuffle: Trueloader:num_workers: 4use_shared_memory: TrueEval:dataset: name: ImageNetDatasetimage_root: /home/aistudio/cls_label_path: /home/aistudio/eval_train_weather_imblearn.txttransform_ops:- DecodeImage:to_rgb: Truechannel_first: False- ResizeImage:resize_short: 256- CropImage:size: 224- NormalizeImage:scale: 1.0/255.0mean: [0.5, 0.5, 0.5]std: [0.5, 0.5, 0.5]order: ''sampler:name: DistributedBatchSamplerbatch_size: 128drop_last: Falseshuffle: Falseloader:num_workers: 4use_shared_memory: TrueInfer:infer_imgs: docs/images/whl/demo.jpgbatch_size: 10transforms:- DecodeImage:to_rgb: Truechannel_first: False- ResizeImage:resize_short: 256- CropImage:size: 224- NormalizeImage:scale: 1.0/255.0mean: [0.5, 0.5, 0.5]std: [0.5, 0.5, 0.5]order: ''- ToCHWImage:PostProcess:name: Topktopk: 5class_id_map_file: ppcls/utils/imagenet1k_label_list.txtMetric:Train:- TopkAcc:topk: [1, 2]Eval:- TopkAcc:topk: [1, 2]

# 覆盖配置
%cd ~
!cp -f  ~/ViT_small_patch16_224_weather.yaml ~/ppcls/configs/ImageNet/VisionTransformer/ViT_small_patch16_224_weather.yaml

# 模型训练
%cd ~/PaddleClas/!python3 tools/train.py \-c ./ppcls/configs/ImageNet/VisionTransformer/ViT_base_patch16_224_weather.yaml \-o Arch.pretrained=True \-o Global.device=gpu

# 模型评估
%cd ~/PaddleClas/!python  tools/eval.py \-c  ./ppcls/configs/ImageNet/VisionTransformer/ViT_base_patch16_224_weather.yaml \-o Global.pretrained_model=./output_weather/ViT_base_patch16_224/best_model

五、预测

1.时间模型导出

# 模型导出
%cd ~/PaddleClas/
!python tools/export_model.py -c ./ppcls/configs/ImageNet/VisionTransformer/ViT_base_patch16_224.yaml -o Global.pretrained_model=./output/ViT_base_patch16_224/best_model

2.开始预测

编辑 PaddleClas/deploy/python/predict_cls.py，按提交格式输出预测结果到文件。

def main(config):cls_predictor = ClsPredictor(config)image_list = get_image_list(config["Global"]["infer_imgs"])batch_imgs = []batch_names = []cnt = 0# 保存到文件f=open('/home/aistudio/result.txt', 'w')for idx, img_path in enumerate(image_list):img = cv2.imread(img_path)if img is None:logger.warning("Image file failed to read and has been skipped. The path: {}".format(img_path))else:img = img[:, :, ::-1]batch_imgs.append(img)img_name = os.path.basename(img_path)batch_names.append(img_name)cnt += 1if cnt % config["Global"]["batch_size"] == 0 or (idx + 1) == len(image_list):if len(batch_imgs) == 0:continuebatch_results = cls_predictor.predict(batch_imgs)for number, result_dict in enumerate(batch_results):filename = batch_names[number]clas_ids = result_dict["class_ids"]scores_str = "[{}]".format(", ".join("{:.2f}".format(r) for r in result_dict["scores"]))label_names = result_dict["label_names"]f.write("{} {}\n".format(filename, clas_ids[0]))print("{}:\tclass id(s): {}, score(s): {}, label_name(s): {}".format(filename, clas_ids, scores_str, label_names))batch_imgs = []batch_names = []if cls_predictor.benchmark:cls_predictor.auto_logger.report()return

# 覆盖预测文件
!cp -f ~/predict_cls.py ~/deploy/python/predict_cls.py

# 开始预测
%cd /home/aistudio/PaddleClas/deploy
!python3 python/predict_cls.py  -c configs/inference_cls.yaml -o Global.infer_imgs=/home/aistudio/test_images -o Global.inference_model_dir=../inference/  -o PostProcess.Topk.class_id_map_file=None

%cd ~
!mv result.txt result_period.txt

/home/aistudio
mv: cannot stat 'result.txt': No such file or directory

3.天气模型导出

# 模型导出
%cd ~/PaddleClas/
!python tools/export_model.py -c ./ppcls/configs/ImageNet/VisionTransformer/ViT_base_patch16_224_weather.yaml -o Global.pretrained_model=./output_weather/ViT_base_patch16_224/best_model

4.天气预测

# 开始预测
%cd /home/aistudio/PaddleClas/deploy
!python3 python/predict_cls.py  -c configs/inference_cls.yaml -o Global.infer_imgs=/home/aistudio/test_images -o Global.inference_model_dir=../inference_weather/  -o PostProcess.Topk.class_id_map_file=None

%cd ~
!mv result.txt result_weather.txt

/home/aistudio

六、合并并提交

1.预测结果合并

period_list = { 0:'Dawn', 1:'Dusk', 2:'Morning', 3:'Afternoon'}
weather_list =  {0:'Cloudy', 1:'Rainy', 2:'Sunny'}

import pandas as pd
import json
data_period= pd.read_csv('result_period.txt', header=None, sep=' ')
data_weather= pd.read_csv('result_weather.txt', header=None, sep=' ')
annotations_list=[]
for i in range(len(data_period)):temp={}temp["filename"]="test_images"+"\\"+data_weather.loc[i][0]temp["period"]=period_list[data_period.loc[i][1]]temp["weather"]=weather_list[data_weather.loc[i][1]]annotations_list.append(temp)
myresult={}
myresult["annotations"]=annotations_listwith open('result.json','w') as f:json.dump(myresult, f)
ather"]=weather_list[data_weather.loc[i][1]]annotations_list.append(temp)
myresult={}
myresult["annotations"]=annotations_listwith open('result.json','w') as f:json.dump(myresult, f)print("结果生成完毕")

结果生成完毕

2.提交并获取成绩

下载result.json并提交，即可获得成绩

3.其他注意事项

生成版本时提示存在无效软链接无法保存 ，可以在终端 PaddleClas 下运行下列代码清理即可。

for a in `find . -type l`
dostat -L $a >/dev/null 2>/dev/nullif [ $? -gt 0 ]thenrm $afi
done
